Thread specification: Metric thread M
Material: Parts A, C, and E are made of UL-approved nylon PA66, while parts B and D are made of nitrile rubber (NBR).
Color: Black, gray, and special colors available upon request.
Operating temperature: Static 40–100°C, with a maximum instantaneous temperature resistance of 120°C; dynamic 20–80°C, with a maximum instantaneous temperature resistance of 100°C.
Features:
Special design of clamping mold and rubber parts, wide range of cable clamping, super strong tensile resistance, waterproof, dustproof, resistant to salt, acid, alkali, alcohol, grease, and general solvents. Protection rating: IP68.
Note: For special sizes and models, please contact us.
Decomposition diagram:
Technical parameters:
Screw specifications | specifications | cable range | Outer diameter of thread | Thread | Wrench diameter | package |
M12*1.5 | MGA12-5.5 | 3-6.5 | 12 | 8.5 | 18/19 | 50 |
MGA12-08 | 4-8 | 12 | 8.5 | 18/19 | 50 | |
M16*1.5 | MGA16-7-ST | 4-7 | 16 | 10 | 22/22 | 50 |
MGA16-10-ST | 6-10 | 16 | 10 | 22/22 | 50 | |
MGA16L-7 | 4-7 | 16 | 15 | 22/22 | 50 | |
MGA16L-10 | 6-10 | 16 | 15 | 22/22 | 50 | |
M20*1.5 | MGA20-11-ST | 6-11 | 20 | 10 | 27/27 | 50 |
MGA20-14-ST | 8-14 | 20 | 10 | 27/27 | 50 | |
MGA20L-11 | 6-11 | 20 | 15 | 27/27 | 50 | |
MGA20L-14 | 8-14 | 20 | 15 | 27/27 | 50 | |
M25*1.5 | MGA25-16-ST | 12-16 | 25 | 12 | 33/33 | 50 |
MGA25-18-ST | 13-18 | 25 | 12 | 33/33 | 50 | |
MGA25L-16 | 12-16 | 25 | 15 | 33/33 | 50 | |
MGA25L-18 | 13-18 | 25 | 15 | 33/33 | 50 | |
M32*1.5 | MGA32-22 | 15-22 | 32 | 12 | 41/42 | 20 |
MGA32-25 | 18-25 | 32 | 12 | 41/42 | 20 | |
MGA32L-22 | 15-22 | 32 | 15 | 41/42 | 20 | |
MGA32L-25 | 18-25 | 32 | 15 | 41/42 | 20 | |
M40*1.5 | MGA40-26 | 20-26 | 40 | 20 | 50/52 | 10 |
MGA40-31 | 24-31 | 40 | 20 | 50/52 | 10 | |
M50*1.5 | MGA50-33 | 25-33 | 50 | 22 | 62/62 | 10 |
MGA50-41 | 31-41 | 50 | 22 | 62/62 | 10 | |
M63*1.5 | MGA63-46 | 39-46 | 63 | 25 | 75/75 | 10 |
MGA63-51 | 44-51 | 63 | 25 | 75/75 | 10 | |
M75*2.0 | MGA75-56 | 50-56 | 75 | 25 | 92/92 | 1 |
MGA75-66 | 56-66 | 75 | 25 | 92/92 | 1 | |
M90*2.0 | MGA90-68 | 58-68 | 90 | 25 | 110/110 | 1 |
MGA90-77 | 66-77 | 90 | 25 | 110/110 | 1 |
