Product Introduction:
The steel nail wire clip is a plastic product injection-molded with PE material. It features high impact resistance and great elasticity, and will never break. The product series is of the nail-insertion type, with the steel nails directly attached to the wire clip, which can greatly save working hours and reduce construction costs.
Product Appearance:
Flat steel nail wire clips, round steel nail wire clips
Usage Method:
Place the wire inside the clip, and use a hammer to drive the steel nail into the wall to fix the wire.
Usage Instruction:
It is generally used for fixing wires in indoor wiring.
Product decomposition:
Technical parameters:
ITEM.NO | （mm） | H1 | R | NAIL | Color |
| F-2.5MM | 3.5 | 2.0 | 2.5 | 1.4X15 | WHITE GREY BLACK BROWN DARK GREY |
| F-4MM | 5.5 | 3.5 | 4.0 | 1.7X14 | |
| F-5MM | 5.5 | 3.5 | 5.0 | 1.7X14 | |
| F-6MM | 6.0 | 4.1 | 6.0 | 1.7X16 | |
| F-7MM | 6.5 | 4.7 | 7.0 | 1.9X16 | |
| F-8MM | 7.0 | 5.0 | 8.0 | 2.1X16 | |
| F-9MM | 8.0 | 5.4 | 9.0 | 2.1X20 | |
| F-10MM | 8.0 | 5.6 | 10.0 | 2.3X21 | |
| F-11MM | 8.5 | 5.6 | 12.0 | 2.3X23 | |
| F-14MM | 10.0 | 7.0 | 14.0 | 2.3X23 | |
| F-18MM | 12.5 | 8.5 | 18.0 | 2.6X27 | |
| F-19MM | 14.0 | 10.5 | 19.0 | 2.6X27 |
