Pin - type insulated terminal
Product Features

Red

Cable size:0.5-1.5mm²(A.W.G.22~16)

Max current:Imax=19A

Material:purple copper


Blue

Cable size:1.5-2.5mm²(A.W.G.16~14)

Max current:Imax=27A

Material:purple copper


Black

Cable size:2.5-4mm²(A.W.G.14~12)

Max current:Imax=37A

Material:purple copper


Yellow

Cable size:4-6mm²(A.W.G.12~10)

Max current:Imax=48A

Material:purple copper

Dimension Drawing

Technical parameters

ITEM NO

Color

Dimension(mm)

B

L

H

PTV 1.25-9

Red

1.9

19.0

10.0

4.3

PTV 1.25-10

1.9

20.0

PTV 1.25-12

1.9

22.0

PTV 1.25-13

1.9

23.0

PTV 1.25-18

1.9

28.0

PTV 2-9

Blue

1.9

19.0

10.0

4.9

PTV 2-10

1.9

20.0

PTV 2-12

1.9

22.0

PTV 2-13

1.9

23.0

PTV 2-18

1.9

28.0

PTV 3.5-10

Black

2.8

20.0

13.0

6.2

PTV 3.5-13

2.8

25.5

PTV 5.5-13

Yellow

2.8

25.5

13.0

6.7
